KingJet KJ-603LUV 3D Effect UV Printer With Imitation Embroidery
The innovative 3D Effect UV Printer can perfectly print embroidery patterns, completely changing the limitations of UV printing textile fabrics and exploring more possibilities for your business.
Main Features:
1. Realistic embroidery effect, with the touch and texture of traditional embroidery, 3D three-dimensional sense.
2. Bright and durable, imitation embroidery products are not easy to fade and can keep bright colors over time.
3. Cost saving: 3D effect UV printer simplifies the process of traditional embroidery and reduces labor and material costs.
4. High productivity: The 3D effect UV printer imitation embroidery printing process is simple and very suitable for mass production.
5. Design flexibility: complex and gradient patterns can be realized.
Configuration Highlights:
- Printhead: 3*EPSON I3200 U1
- Printing Speed: 6 pass: 2.5 sqm/h
- Max Printing Width: 600mm
- Color: CMYK+W
- RIP Software: Maintop, Photoprint
Product Features
Perfect 3D imitation embroidery effect
You can print 3D imitation embroidery patterns with bright colors, durability, and perfect details on specific fabrics, breaking the limitations of UV printing.
High performance
The front stepper motor has greater power, stable stepping, and smooth print output.
EPSON original printhead
3*EPSON I3200 U1 original printheads for high-precision and fast printing.
UV water cooling system
Used with a UV lamp, it can speed up ink drying and further improve production efficiency.
Automatic nozzle cleaning
Elevating aluminum capping system, automatic cleaning, saving manual maintenance time and energy.
White ink circulation system
It can reduce nozzle blockage, protect the nozzle, and extend service life.
3D Effect UV Printer printing video
3D Effect UV Printer Printing process
Product Specification
| Product | KJ-603 LUV 3D effect UV printer |
| Model | KJ-603 LUV |
| Printhead | 3*EPSON I3200 U1 |
| Printing Speed | 6pass: 2.5sqm/h |
| Max Printing Width | 600mm |
| Color | CMYK+W |
| Ink Type | Special UV ink |
| Ink Supply System | White ink stirring |
| Media Type | Special UV DTF AB film, waste discharging film |
| Application | All kinds of fabrics, leather, shoe materials, etc., can stand with high temperatures and sticky object surface |
| Curing System | UV LED curing system |
| Capping & Moisturizing | Auto capping system & moisturizing system |
| RIP Software | Maintop, photoprint |
| Input Power | AC110V/220V, 50HZ/60HZ |
| Working Environment | Temperature: 18-32℃, humidity: 46-65% |
| Machine Size | 1900*850*1420mm, 280kg |
| Water Tank Size | 110V: 420*355*220mm, 11.5kg; 220V: 360*300*220mm, 10.5kg |
| Machine Packing Size | 2440*1000*860mm, 380kg |
| Water Tank Size Packing Size | 110V: 530*430*440mm, 13kg; 220V: 450*390*350mm, 12kg |
3D Effect UV Printer Applications
Using a double-layer heat press machine to heat press the pattern twice, it can be applied to fabrics that don’t need to be washed for a long time, such as flags, leather, scarves, shoe materials, etc. The colors are bright, the imitation embroidery has a good hand feel, and the pattern has a high-end texture.
FAQ
What is the difference between 3D Effect UV Printer and ordinary UV DTF machine?
1. Different configurations of the machine
The UV lamp is different, and the ink path is different, but the appearance of the machine is the same.
2. Different application range
UV DTF printer can be applied to various types of materials, such as glass, metal, acrylic, plastic, ceramic, etc.
3D effect UV printer is mainly applied to textile fabrics with less washing, such as flags, leather, etc. It is durable and long-lasting, and the embroidery pattern has a strong texture.
Is the 3D effect UV machine complicated to use?
No, it is very simple. After the pattern is printed, you only need to use a double-layer heat press machine to heat press the pattern twice to complete the embroidery pattern.
Can a 3D Effect UV Printer be converted into a normal UV DTF printer?
It is not recommended because the printing principles and configurations of the two machines are different, which may cause machine failure.
