KingJet KJ-302A Direct To Film Printer

The DTF printer with good economical and stable performance is equipped with EPSON XP600 print head, which is lower in cost than the I3200 A1 print head, greatly reducing the printing start-up cost.

Printhead: 2*epson i3200A1 ; 2*epson i1600A1 ; 2*epson xp600

Printing Speed: 4pass:12sqm/h,6pass:9sqm/h ; 4pass:6sqm/h,  6pass:5sqm/h ; 4pass:5sqm/h, 6pass:4sqm/h

Max Print Width: 420mm

Color: 5 colors (C, M, Y, K, W)

RIP Software: maintop, photoprint, CADlink

7* 0 hours
Online technical support
1 years
Warranty Lifetime Service
0 sqm
Production area
0
Dealer market protection

Product Advantages

High cost performance

Equipped with Epson XP600 Head,it greatly reduces starting costsis since it's lower cost than I3200 A1 heads.

Precise printing

The machine is equipped with a 42cm printing width, which perfectly adapts to A2 size printing needs and meets personalized customization requirements.

Convenient

The automatic take-up system saves the time and energy of manually adjusting printing materials, making it more convenient and efficient.

Environmentally friendly ink

The DTF ink used is green and environmentally friendly, making printing more sustainable.

Product Main Features

White ink circulation system

Maintain the continuous flow of ink and prevent nozzle clogging to achieve uninterrupted production.

Industrial grade precision platform

Keep the printing flatness at 0-0.5mm, making the printing surface flatter and printing accuracy higher.

Lifting trolley frame

Automatically adjust the printing height during the printing process to avoid collision or damage to the nozzle.

Anti-warping clamps

Apply even pressure to eliminate wrinkles on the material surface and make the printing surface smoother.

Product printing Process

Product Specification

Product KJ-302A DTF printer
ModelKJ-302A
Printhead 2*EPSON I3200A12*EPSON I1600A12*EPSON XP600
Printing Speed4pass: 12sqm/h, 6pass: 9sqm/h4pass: 6sqm/h, 6pass: 5sqm/h4pass: 5sqm/h, 6pass: 4sqm/h
Color5 colors (C, M, Y, K, W)
Max Media Width 430mm
Max Print Width420mm
Ink TypeWaterbased pigment ink
Media TypePET film
Heating SystemIntelligent embedded heating system & powder melt machine
Feed & Take up SystemEquipped
Ink systemAutomatic ink supply white ink circulating and stirring
ClampCombined anti-warping clamps
Power Electric Supply 110V/220V,50-60HZ
Power 350W-3400W
RIP SoftwareMaintop,photoprint,CADlink(optional)
Working EnvironmentTemperature: 18-32℃ , humidity: 46-65%
Printer Size1100*510*625mm, 70kg
Shacker Size800*510*510mm, 50kg
Packing SizePrinter: 1320*730*850mm, 105.5kg , 0.480cbm
Shaker: 880*610*730mm, 70kg , 0.440cbm

Get In Touch With Us

Product Applications

CMYK+W 5 colors can be applied to more than 90% of fabrics, regardless of color, and can be produced in batches

Related Products

No nozzle clogging, less dosage, Print clearly, available in CMYK+W and fluorescent color.

High temperature resistant, washable, high color fastness, available in black powder, white powder, medium powder and fine powder.

Provide various PET films, such as hot/cold/instant peeling film; single/double side film; A3/30/60cm pet film; gold/silver/glitter/gold foil PET film.

It is intelligent, efficient and multi-functional.The printing is clear, the operation is convenient, and it supports large-volume printing.

FAQ

Requires DTF printer, DTF ink, PET film, and DTF hot-melt powder to be used together.

The printhead used in our Kingjet DTF printer are EPSON I3200A1/I1600A1/XP600 and all of our printhead is original and brand new.

Any fabric which can stand 170℃ heat press temperature can be transferred by DTF, like cotton, T-shirts, jeans, canvas, sweatshirts, polyester, etc.

Print cost for 1 sqm transfer fabric pattern is about 1-2 USD, and about 0.07-0.1usd for A4 size Printing.

If print 1 sqm pet film pattern, it needs the following consumables: CMYK(total 4 color): 10-15ml;white:15-30ml;powder:10-20g

Print the designed pattern on the PET film, then evenly sprinkle hot melt powder on the pattern, melt it at high temperature and then dry it, cut the PET film, and heat-press the pattern onto various types of clothing through heat press, and then you can complete the clothing printing!

Under normal wear and standard washing operations, DTF print can usually withstand approximately 50 to 100 washing cycles in accordance with the international washing standard.

Equipped with a peristaltic pump with imported medical BRT tubes, XY-axis laser servo integrated motor, intelligent multi-function temperature controller, front platform heating width of 12cm, round bottle large-capacity white ink mixing ink cartridge, etc., the printing quality is better than other DTF printers.

Currently, we use single-phase power for KingJet DTF printer. you only need to tell us your local single-phase voltage and plug standard, and we will customize machine according to your needs. 110V and 220V voltage are available.

Printer with one year guarantee, printheads and consumable parts without guarantee. If you need help, we can provide long-term after-sales service.

One-stop services

Comprehensive service starting from pre-sale to after-sale to help your business on track.

Free Printing Sample

To show the quality and capability of our printer to satisfy your needs, we will send you a free video demonstration showing its operation. And you can get free samples for consumables.

Fast Delivery

To meet everyone’s order quickly, we have established branches in many places around the world, saving transportation time. Products in stock usually ship within 3-5 days.

Lifetime service

You can enjoy one-year warranty on the main components of our brand machines, lifetime service for the entire machine operation, free after-sales consultation, and 24/7 technical support services.
