KingJet KJ-3240UV Large Format Flatbed UV Printer with Maglev Technology
The industrial large-format flatbed UV printer uses innovative magnetic levitation technology, which has unparalleled printing accuracy and excellent stability compared to traditional printers, bringing strong competitiveness to the mass production of furniture table boards, decoration building materials, cabinet wood materials, etc.
Key Features:
1. Premium double-layer German Igus drag chain, more stable and durable.
2. 6 vacuum adsorption platforms concentrate energy and save energy.
3. Automatically detect the position and direction of the object, improve positioning accuracy and work efficiency.
4. Maglev technology abandons the structure of the ordinary motor+belt, reducing faults and saving maintenance.
Configuration Highlights:
- Printhead: 4-9 industry printheads
- Print Size: 3.2m*4m
- Thickness: 0-10cm
- DPI: 1200 dpi
- Color: CMYK, LC, LM, W, V (optional)
- RIP Software: Aurelon, Photoprint, Onyx optional.
Maglev Flatbed UV Printer features
Magnetic levitation configuration
Compared with traditional transmission methods, magnetic levitation can carry higher movement speed, higher printing accuracy, lower noise, and reduced component wear problems.
Free combination of printing solutions
In addition to CMYK+LC+LM, white channel and varnish channel are also provided to show high visual artistic effects and unique embossed three-dimensional effects.
Automatic point-seeking and positioning function
The air suction hole on the printing platform is a good positioning function, making the printed object pattern more accurate.
Automatic height measurement
Built-in height measurement probe. When the thickness of the medium exceeds the bottom of the head, the height measurement probe will be automatically triggered, and the head will automatically rise and fall to the appropriate printing height.
Color and white double negative pressure system
Ensures the uniform distribution of different color inks, without ink leakage or insufficient ink supply, greatly improving printing quality and efficiency.
Y-axis dual motor
Provides greater power, high-precision and high-speed printing, stable and reliable, especially suitable for large-size printing tasks.
Product Parameter
| Product | Maglev Flatbed UV Printer |
| Model | KJ-3240 |
| Printhead | 4-9 industry printheads |
| High Speed Mode | 35m²/h, 54m²/h, 72m²/h |
| Production Mode | 23m²/h, 36m²/h, 48m²/h |
| Quality Mode | 16m²/h, 26m²/h, 38m²/h |
| Print Size | 3200*4000mm |
| Printing Method | Piezojet greyscale printing technology |
| DPI | 1200dpi |
| Ink Type | UV ink |
| Color | CMYK, LC, LM, W, V (optional) |
| Sofware RIP | Aurelon, Photoprint, Onyx (optional) |
| Ink Cartridge Size | 1.5L |
| Color Management | ICC color curve offered, adjustable by user |
| Thickness | 0-10cm |
| Platform Type | 6 zones, freely switchable, suction and blowing air can be selected according to demand |
| Material | Acrylic, wood, glass, ceramic tile, metal, PVC, industrial film, etc. |
| Ink Supply System | Dual negative pressure system in color and white |
| Solidification System | Solidification with UV LED light |
| Operational Environment | Temperature: 20-30℃, relative humidity: 35%-65%, non-condensing |
| Operating System | Windows 10, 64-bit, USB2.0/3.0, HDD 500G+ |
| File Format | Tiff, Jpeg, Postscript, EPS, PDF, etc. |
| Power | 6000W, 28A |
| Input Voltage | 200-240V AC, 50HZ |
| Machine Size | L5480*W4760*H1530mm, 3200KG |
| Packing Size | L5800*W2300*H1920mm/L3800*W2300*H1450mm, 3600KG |
Get In Touch With Us
Other Magnetic levitation UV flatbed printers
- 2.5×1.3m Printing Width
- Color: CMYK, LC, LM, W, V (optional)
- 4-9 industrial print heads
- High precision and bright colors.
- Print almost all flat materials: ceramics/wood/stone building materials/cabinet wood boards/advertising signs, etc.
- 3.2x2m printing width
- Color: CMYK, LC, LM, W, V (optional)
- 4-9 industrial print heads
- Stable, high-quality printing performance.
- Various printing effects: embossing/matte/varnish/frosted/gold & silver effects.
Large Format Maglev Flatbed UV Printer Applications
Background wall
slate stone dining table
Ceramic tiles
UV flatbed printer for Wood
Glass
Maglev flatbed printer for billboard
FAQ
What is magnetic levitation UV flatbed printer?
The working principle of magnetic levitation technology is to use electromagnetic technology, combined with the position signal of the sensor to generate a control current, so that the electromagnet generates electromagnetic force on the suspended object, thereby driving the suspended object to move.
Therefore, adding magnetic levitation technology to the UV flatbed printer can achieve high-speed, high-precision and high-stability printing, and at the same time solve the problem of component wear caused by the traditional belt drive form, which is an innovative breakthrough in UV printing technology.
What materials can Maglev Flatbed UV Printer print?
Supports almost all flat materials, such as hard materials: glass, metal, tiles, wood boards, acrylic, PVC boards; soft materials: leather, TPU mobile phone cases, etc.
Specific application scenarios: advertising light boxes, home decoration background walls, cabinet wood boards, mobile phone case customization, furniture panel printing, etc.
What are the advantages of Maglev Flatbed UV Printer over ordinary UV flatbed printer?
1. Magnetic levitation technology reduces mechanical wear and improves printing speed and efficiency.
2. Contactless printing, suitable for a variety of materials and colors, with higher printing quality.
3. Environmentally friendly, low noise, more comfortable to use.
Does the Maglev flatbed printer support curved surface printing?
No. Maglev flatbed UV printers are mainly used to print large format flat objects, focusing on high speed, high precision and mass production.
Is the maintenance cost of Maglev Flatbed UV Printer high?
Compared with traditional printers, the maintenance cost of magnetic levitation flatbed UV printers may be higher, because its technology is more advanced and its components are more precise. However, in the long run, it is more cost-effective as its printing is efficient and durable.
